Description

MEASUREMENTS PER UNIT:

18 SQUARE METERS/ 193 SQUARE FEET: WIDTH 3 METERS/ 9.84 FEET, LENGTH 6 METERS/ 19.70 FEET, HEIGHT 2.80 METERS/ 9.20 FEET.

ALL UNITS INCLUDE:

FIVE (5) TOILETS, TWO (2) URINAL, SIX (6) WASHBASIN, WALL AND CEILING FINISHES WITH COLOR OPTIONS: BLACK, WHITE, GRAY OR NATURAL. MANUAL, INSTRUCTIONAL VIDEOS AND TECHNICAL SUPPORT, THE PRODUCT IS DELIVERED DISASSEMBLED, TRANSPORT AND ASSEMBLY SERVICE AVAILABLE. (AVAILABILITY SUBJECT TO PURCHASE VOLUME).

MATERIALS DESCRIPTION:

STRUCTURE: GALVANIZED AND STEEL, PAINTED WITH ELECTROSTATIC PAINT. SPECIFICATIONS IN QUOTATION.
WALLS: GALVANIZED REINFORCED, SOUNDPROOFING, A GRADE FIREPROOF WITH THERMAL INSULATION ROCK WOOL, PANEL OF 2.53 METERS/ 8.30 FEET LONG, BY .95 CENTIMETERS WIDE/ 3.28 FEET WIDE, PAINTED OR NATURAL.
ROOF: 16 CENTIMETERS/ 6.30 INCHES TOTAL THICKNESS IN SLAB, 4 COMPONENT REINFORCED PANEL; CEILING PANEL, A GRADE FIREPROOF WITH THERMAL INSULATION ROCK WOOL, GALVANIZED STEEL STRUCTURE REINFORCEMENT, EXTERIOR GALVANIZED SHEET. SPECIFICATIONS IN QUOTATION.
FLOOR: 18 MM VITROMAGNESIUM CEMENT FLOOR, PIECE OF 2.79 METERS LONG BY 1.48 METERS WIDE/ 9.15 LONG BY 4.86 INCHES WIDE, 0.71 INCHES/ THREE QUARTERS (3/4) THICK. WITH OR WITHOUT 3 MM PVC FINISH COATING/1/8 (0.1181 INCH)
